Using the front control panel

The front control panel contains buttons for turning the display on and off, controlling the volume, freezing and unfreezing the screen, and going to the Home screen.

The front control panel also includes a light that indicates the display’s current power state.

Position of the five buttons on the front control panel numbered 1 to 5 - left to right

No.

Name

Procedure

For more information

1

Remote control receiver and ambient light sensor

N/A

N/A

2

Power, and status light

SeeTurning on and turning off the display

3

Home

Return to the Home screen.

N/A

4

 Freeze

Press to freeze and unfreeze the screen.

SeeFreezing the screen

5

Volume decrease

Press to turn down the volume.

SeeAdjusting the volume

6

Volume increase

Press to turn up the volume.

SeeAdjusting the volume

The Power button’s color indicates the display’s status:

Power button

Display status

Off

Not receiving power

Amber (solid)

Standby mode

Green

Ready mode

Green

Normal operating mode

Amber/green (blinking, slow)

Background process running (for example, a firmware update is in progress)
