SMART kapp iQ 65-V2 specifications

DViT (Digital Vision Touch) technology

8 touches 1 Requires SMART Product Drivers to be installed. Some applications might not support 8 touches. Only up to 4 touch points and no pen support on Chrome OS operating system.

Behavior adjusts automatically to the tool or object you’re using, whether it’s a pen, finger, eraser or palm.

Two people can write independently and simultaneously, using different colored ink.

LED

16:9

3840 × 2160 at 30 Hz (HDMI) or 60 Hz (DisplayPort)

26.97–75.0 kHz

23.9–60.32 Hz

1200:1

338 cd/m²

0.372 mm × 0.372 mm

68% of NTSC

178°

8 ms

Presence detection sensor on the bottom frame

10 W rear-facing integrated speakers (×2)

<35 dBA

SMART kapp iQ appliance

8' (2.4 m) country-specific power cable

Pen (×2)

IEEE 802.11A/B/G/N/Ac with 2 × 2 MIMO (both 2.4 and 5 GHz bands)

Bluetooth 4.2 dual mode (backwards compatible with Bluetooth 2.1 + EDR)

Establish a Bluetooth wireless connection with a supported mobile device (see below) by scanning the interactive display’s unique QR code

For a standard VESA 300 mm × 400 mm mounting plate

Lower mounting holes 13 3/4" (35 cm) from the bottom of the board

Minimum depth of 1 5/8" (4.2 cm) for all components on the back of the board to clear the wall

Connector panel

OPS slot (for the iQ appliance)

HDMI1 input connectors
HDMI in
USB Type-B

HDMI2 input connectors
HDMI in
USB Type-B

DisplayPort input connectors
DisplayPort in
USB-Type-B

Stereo 3.5 mm out

RS-232 in

SMART kapp iQ appliance

USB 3.0 Type-A (×2)

USB 2.0 Type-B 2 For service use only

OPS/HDMI input connectors
HDMI in
USB Type-B

HDCP encrypted HDMI 1.4 out

RJ45

AC power inlet

See the SMART kapp iQ boards administrator’s guide (docs.smarttech.com/kb/171038)

iOS 9 or later operating system software

50 MB of storage

iPhone 4S or later

Third-generation iPad or later

First-generation iPad mini or later

Fifth-generation iPod touch or later

Android 4.4.4 (KitKat) or later operating system

50 MB of storage (internal or SD card)

1024 MB of RAM

720p or better screen resolution

Bluetooth 2.1 + EDR

3 megapixel or better rear-facing camera (recommended)

Safari for iOS 9 or later operating system software

Chrome for Android 39.0.2171.93 or later

Internet Explorer 10 or later

Chrome 39.0.2171.95 or later

Firefox 34.0.5 or later

Safari 8.0 or later

See the SMART Notebook software release notes

Graphics card that can support 3840 × 2160 resolution at 30 Hz and that has 1 GB DDR 5 memory

See Minimum requirements for Ultra High Definition or 4K on your interactive flat panel

See the SMART Notebook software release notes

Smaller than 10" × 10" × 2" (25.4 cm × 25.4 cm × 5.1 cm)

Less than 10 lb. (4.5 kg)

VESA 75 mm × 75 mm or 100 mm × 100 mm mounting pattern

Maximum length: 23' (7 m)

DisplayPort 1.2 compliant or better

Maximum length: 23' (7 m)

Maximum length: 16' (5 m)

Using cables that exceed these maximum lengths can produce unexpected results, such as degraded picture quality or USB connectivity. Refer to SMART installation standards (docs.smarttech.com/kb/171035) for comprehensive information about cables and extensions for SMART hardware products.

100V to 240V AC, 50 Hz to 60 Hz

15 W

113 W

189 W

<2.2 W

110 W

41–95°F (5–35°C)

-4–140°F (-20–60°C)

5–80% relative humidity, non-condensing

UL (U.S./Canada), FCC, IC, CE, RCM, PSE

REACH, RoHS, WEEE and Packaging

Packaging and Conflict Minerals

SMART kapp iQ 65‑V2 board

Fixed wall mount for SMART Board interactive displays

See smarttech.com/accessories

Two-year limited equipment warranty
