PCM12-i5 series specifications
PCM12-i5 Processor (Alder Lake) | Intel Core i5 12450H |
|---|---|
Memory | 8 GB DDR4 |
Storage | 256 GB M.2 NVMe SSD |
Graphics | Intel UHD Graphics |
4K UHD video | Yes, Full 4K UHD, 60 Hz |
Operating system | Windows 11 Pro, Full license |
LAN | Gigabit Ethernet Intel I219 |
Wireless | Intel Wireless (2.4 GHz/5 GHz/BT) IEEE 802.11ax (Wi-Fi 6) Bluetooth 5.2 |
SMART displays and softwareSupported SMART Board interactive displaysNote
Install the OPS PC module in the accessory slot of supported SMART Board interactive displays.
Available SMART software
| SMART Notebook SMART TeamWorks SMART Meeting Pro SMART Remote Management |
|---|
Storage and operating requirementsPower requirements | 12V to 19V DC |
|---|---|
Operating temperature | |
Storage temperature | |
Humidity | 10–90% relative humidity, non‑condensing |
Power consumptionStandby | <0.5 W |
|---|---|
Maximum | 76 W |
Certification and complianceRegulatory models |
|
|---|---|
India |
|
Performance / interoperability certifications |
|
Notes
Product availability may vary by region.
This product has received additional certifications not listed here.
Purchasing informationOrder numbersPCM12-i5-IN-3A | OPS PC module with Windows Pro, i5 processor, India |
|---|
SMART Warranty
| Terms and conditions and warranty upgrade options vary by region. Visit smarttech.com/warranty or contact your reseller for information. |
|---|
Hardware components
No. | Component | Qty |
|---|---|---|
A | Antennas | 2 |
B | Power and hard drive status lights | 2 |
C | Power button | 1 |
D | Kensington Security Slot | 1 |
Inputs and outputs
No. | Type | Qty |
|---|---|---|
1 | Stereo 3.5 mm | 1 |
2 | HDMI 2.0 out | 1 |
3 | USB 3.2 Type-C | 1 |
4 | USB 3.2 Gen 1 Type-A | 4 |
5 | RJ45 (including indicator lights) | 1 |
Installation, dimensions, and weightsNote
All dimensions and weights ±10%.
Dimensions
